Electrical Specifications
Specification Description
Power Supply
1.5 V, size AAA, exchangeable Lithium/iron disulfide FR03 (recommend-
ed) or alkaline LR03
Power Consumption max. 120 mW
Materials
Component Material
Housing PC (Polycarbonate) / ABS (Acrylnitril-Butadien-Styrol-Copolymer) blend
Tip Medical stainless steel
Isolator PEEK (Polyetheretherketone)
Environmental Specifications
Specification Transport/Storage Conditions Operating Conditions
Temperature -10 °C to 50 °C (14 °F to 122 °F) 10°C to 35°C (50°F to 95°F)
Humidity 10% to 90% noncondensing 20% to 80% noncondensing
Pressure 500 hPa to 1060 hPa 700 hPa to 1060 hPa
Optical Specifications
Specification Color Description
Infrared LED N/A Wavelength: λ = 870 nm (IR-A)
Visible status LED
Green Wavelength: λ = 570 nm
Red Wavelength: λ = 630 nm
Certifications and Classifications
Certification
IEC 60601-1
Classifications According to
Internally Powered ME Equipment for Continuous Operations IEC 60601-1
IP44 IEC 60529
Exempt group: LEDs do not pose any photobiological hazards
Softouch Pointer Technical Information
44 Instrument User Guide Rev. 2.3 Cranial/ENT Optical
