# From To Cable
Length
Cable Di-
ameter
Largest Plug Diame-
ter
Minimum Conduit Di-
ameter
S
Generator cab-
inet 1 (2.0a)
Generator cabinet 2
(2.0b)
5 m (op-
tional 20
m)
2x 6, 24
mm
35 mm
75 mm (low and high
voltage cables togeth-
er in the same conduit,
no sharp turns)
T
In-room distri-
bution box
(1.3)
Flat panel detectors
(2.3a/2.3b)
n/a 9 mm No plug
25 mm (see page
77)
U
Computer cabi-
net (1.0)
Hospital network
(4.0)
4 m 5 mm 14 mm 25 mm
1)
The cabling from the computer cabinet to the in-room power box and the flat panels can be
placed together in a single 100 mm conduit.
2)
Depending on system configuration, one or two cables are required.
3)
A 130 mm conduit is required from generator 1 to floor box 1 (labeled “a”) and from generator 2
to floor box 2 (labeled “b”). If generators 1 and 2 are positioned directly next to each other, it is
possible to place both X-ray tube cables into a single conduit. In this case, separate the high
voltage cables from the data cables.
Cabling
22 Site Planning Manual Rev
. 1.0
