Requirements for Custom-Made Ceiling Mount
If it is impossible to install the ceiling mount at the required position, you can provide an interface
plate and a custom-made ceiling mount according to the following requirements:
50mm
Ceiling
= space for mounting screws-
must be easy reachable
120mm
170mm
10,5mm
8mm
Custom made ceiling plate
~60mm
~220mm
Custom made ceiling plate
Figure 25
You are responsible for adhering to safety factors, local regulations and mounting the
custom made interface plate and custom-made ceiling mount.
CEILING AND WALL MOUNTS
Site Planning Manual Rev. 1.0 ExacTrac Ver. 6.x 57
