System User Guide Rev. 2.5 Kolibri Ver. 2.0 27
KOLIBRI WORKSTATION
Ports Used for 3rd-
Party Connections
Serial 2
For safety reasons, cover serial port a with a cap if no cable is connected.
LAN
Only connect IEC compliant devices to LAN ports.
Microscopes
Before powering on the surgical microscope and
Kolibri
workstation, perform the follow steps:
No. Port Comment
a
Serial 2
See page 27
s
VGA Output/Loop
d
Real-time video in
•Optional
• To connect a device, e.g., endoscope
• Composite connection
• Can be hotplugged
f
Video in 1
•Optional
• To connect a device, e.g., C-arm, microscope, ultrasound
• Composite connection
• Can be hotplugged
g
CANBUS Optional; to connect a device, e.g., Leica microscope
h
Video out S-video
j
Video out Composite
k
Loop Connected to port VGA Output/Loop s by a dedicated cable
l
S-video
•Optional
• Function as Video in 2
• To connect a device, e.g., C-arm, microscope, ultrasound
• S-VHS connection
• Can be hotplugged
;
Gigabit Ethernet
Can be hotplugged
A
4 USB
S
10/100Mbps LAN
D
IEEE 1394
• To connect a device, e.g.,
IGSonic
• Can be hotplugged
F
Keyboard
See page 29
G
Mouse
Steps
1. Connect all required cables.
2. Power on the surgical microscope and wait until boot up is complete.
3. Power on
Kolibri
workstation.
