100-214-276 Rev. 3 2-1
2000X aed Actuator Chapter 2: Introduction to the 2000X aed Actuator
Instruction Manual Models Covered
Chapter 2: Introduction to the 2000X aed
Actuator
2.1 Models Covered- - - - - - - - - - - - - - - - - - - - - - - - - - 2-1
2.1.1 Power Supply Manual Set - - - - - - - - - - - - - - - - - - - 2-3
2.2 Overview of this Model - - - - - - - - - - - - - - - - - - - - - - 2-3
2.3 Features of the System - - - - - - - - - - - - - - - - - - - - - - 2-4
2.4 Controls and Indicators - - - - - - - - - - - - - - - - - - - - - - 2-6
2.5 Welding Systems - - - - - - - - - - - - - - - - - - - - - - - - - 2-7
2.6 Glossary of Terms - - - - - - - - - - - - - - - - - - - - - - - - 2-9
The 2000X Actuator provides motion, force, power (from the power supply), and cooling air to
the ultrasonic stack assembly. The 2000X aed Actuator is designed to work with a Branson
2000X distance Power Supply.
2.1 Models Covered
This manual covers the Branson 2000X aed Actuator. The 2000X aed Actuator may be found in
one of several configurations:
• An Actuator on a Column Support, Column and Ergonomic Base, also called a Stand on
Base (as seen on the following page)
• An Actuator on a Column Support, Column and Mounting Hub, sometimes called a Stand on
Hub
• An Actuator alone (not installed on a Column Support, and so on.). These are often used in
custom or automated systems that provide a means of positioning the Actuator.
This manual covers these configurations. A 2000X-series actuator requires a 2000X-series
power supply to function, and that is covered in separate manuals and user documents.
DOC EXPIRES 12PM 7/24/2012. Article or Material must comply with the requirements
stipulated by RoHS in its current version
