100-214-276 Rev. 3 4-27
2000X aed Actuator Chapter 4: Installation and Setup
Instruction Manual Installation Steps
Table 4.6 User I/O Cable Pin Assignments.
Pin Signal Name Signal Type Direction Signal Range Definition Colors
7 ACT_CLEAR 24V Logic 0
True
Output 0/24V, 100mA Actuator clear signal Red/Wht
24 AMPLITUDE_OUT Analog Output 0V to 10V Amplitude signal from PS Red/Blk/
Grn
2 CYCLE_ABORT 24V Logic 1
True
Input 0/24V, 100mA Red/Blk
3 EXT_RESET 24V Logic 1
True
Input 0/24V, 100mA System Reset Grn/Blk
18 EXT_SEEK+ 24V Logic 1
True
Input 0/24V, 100mA Red/Blk/
Wht
38 FREQ_OUT Analog Output -10V to +10V Frequency Signal from PS Blk/Wht/Blu
6 G_ALARM 24V Logic 0
True
Output 0/24V, 100mA Blk/Wht
14 GEN_ALARM_RELAY_1 Relay Contact Output 40V, 0.25A Contact Closure Red/Grn
29 GEN_ALARM_RELAY_2 Relay Contact Output 40V, 0.25A Contact Closure Wht/Red/
Orn
1 J3_1_INPUT 24V Logic 1
True
Input 0/24V, 100mA User definable inputs. Refer
to Table 4.6 to view available
selections.
Wht/Blk
17 J3_17_INPUT 24V Logic 1
True
Input 0/24V, 100mA Wht/Blk/
Red
19 J3_19_INPUT 24V Logic 1
True
Input 0/24V, 100mA Grn/Blk/
Wht
31 J3_31_INPUT 24V Logic 1
True
Input 0/24V, 100mA Wht/Red/
Blu
32 J3_32_INPUT 24V Logic 1
True
Input 0/24V, 100mA Blk/Wht/
Grn
33 J3_33_INPUT 24V Logic 1
True
Input 0/24V, 100mA Wht/Blk/
Grn
8 J3_8_OUTPUT 24V Logic 0
True
Output 0/24V, 100mA User definable outputs. Refer
to Table 4.7 to view available
selections.
Grn/Wht
22 J3_22_OUTPUT 24V Logic 0
True
Output 0/24V, 100mA Blk/Red/
Grn
36 J3_36_OUTPUT 24V Logic 0
True
Output 0/24V, 100mA Orn/Red
Grn
9 MEM Analog Output -10V to +10V Memory Signal from PS Blu/Wht
11 MEM_CLEAR Open Collector Output 24V, 25mA max Memory Clear signal send to
PS
Wht/Red
40 MEMORY_STORE Open Collector Output 24V, 25mA max Memory store from PS Red/Wht/
Blu
34 PB_RELEASE 24V Logic 0
True
Output 0/24V, 100mA Red/Wht/
Grn
37 PWR Analog Output 0V to 10V Power Signal from PS Blu/Red/
Grn
21 READY 24VLogic 0
True
Output 0/24V, 100mA Blu/Blk/Wht
5 REJECT 24V Logic 0
True
Output 0/24V, 100mA Blu/Blk
