Branson 2400 - Servicing Specifications

BRAKE
KUKJE MACHINERY CO., LTD.
113
3. SERVICING SPECIFICATIONS
Item Factory Specification Allowable Limit
Brake Pedal Free travel
30.0 to 40.0 mm
1.18 to 1.57 in.
-
Clearance
0.0 to 0.165 mm
0.0 to 0.00649 in.
1.0 mm
0.0039 in.
Pedal Shaft(O.D.)
24.967 to 25.030 mm
0.98295 to 0.98543 in.
-
Pedal Shaft to Center Frame
Bush(I.D.)
25.03 to 25.081 mm
0.98543 to 0.98744 in.
-
Cam Plate and Bearing Holder Flatness -
0.3 mm
0.012 in.
Cam Plate and Ball Height
22.89 to 22.99 mm
0.9012 to 0.9051 in.
22.40 mm
0.8819 in.
Brake Disc Thickness
3.3 to 3.5 mm
0.130 to 0.138 in.
3.0 mm
0.118 in.
Friction Plate Thickness
3.14 to 3.96 mm
0.124 to 0.128 in.
2.74 mm
0.108 in.
