Branson 2400 - Power Train for Traveling System; 1> Main Gear Shaft Section (Manual Transmission Type)

TRANSMISSION
KUKJE MACHINERY CO., LTD.
64
1. POWER TRAIN FOR TRAVELING SYSTEM
<1> MAIN GEAR SHAFT SECTION (MANUAL TRANSMISSION TYPE)
1) Gear shaft
2) Gear reverse
3) Gear
4) Gear shaft
A : Front cover
B : Transmission case
1) Ball joint shaft
2) Gear shaft
3) Gear shaft
4) Gear
5) Gear shaft
