Branson 2400 - 2> Preparation; Separating Housing

TRANSMISSION
KUKJE MACHINERY CO., LTD.
76
5. CHECKING, DISASSEMBLING AND SERVICING
<2> PREPARATION
1) Separating Housing
< Draining transmission fluid >
1. Place an oil pan underneath the transmission
case, and remove the drain plugs(1).
2. Drain the transmission fluid.
3. Reinstall the drain plug.
▷ Refilling
9 Fill new oil from filling port after removing the
filling plug(2) up to the upper notch on the
dipstick(3).
9 After running the engine for few minutes, stop it
and check the oil level again, if low, add oil to
proper level.
◈ Important
9 Use only multi-grade transmission oil. Use of
other oils may damage the transmission or
hydraulic system.
9 Never work the tractor immediately after
changing the transmission oil. Keep the engine
at medium speed for a few minutes to prevent
damage to the transmission.
9 Do not mix different brands oil together.
Front
Case
3.0 L
0.79 U.S.gals
0.66 lmp.gals
2100
2400
2800
Rear
case
13.0 L
3.43 U.S.gals
2.86 lmp.gals
Transmission
Fluid capacity
HST
Rear
case
15.0 L
3.96 U.S.gals
3.3 lmp.gals
*. PART NAME
1) Drain plug 2) Filling plug
3) Dipstick
(1)
(1)
(1)
(2)
(3)
