Branson 2400 - Servicing Specifications

TRANSMISSION
KUKJE MACHINERY CO., LTD.
68
3. SERVICING SPECIFICATIONS
Item Factory Specification Allowable Limit
Check and high pressure relief
valve
Setting pressure
(Relief valve)
30.9 to 31.9 MPa
315.0 to 325.0 kgf/㎠
4480 to 4622 psi
-
Charge relief valve Setting pressure
392.0 to 490.0 MPa
4.0 to 5.0 kgf/㎠
56.9 to 71.1 psi
-
Shift fork to shift gear groove Clearance
0.10 to 0.35 mm
0.004 to 0.014 in.
0.50 mm
0.020 in.
Clearance
0.027 to 0.067 mm
0.0011 to 0.0025 in.
0.10 mm
0.0039 in.
Front wheel drive shaft
(O.D.)
21.967 to 21.980 mm
0.8648 to 0.8654 in.
-
16T-20T Gear (I.D.)
28.007 to 28.021 mm
1.1024 to 1.1032 in.
-
16T-20T Gear to front wheel drive
shaft
Needle (O.D.)
2.996 to 3.000 mm
0.1179 to 0.1181 in.
-
Clearance
0.020 to 0.026 mm
0.0008 to 0.0010 in.
0.10 mm
0.0039 in.
Mid-PTO shaft (O.D.)
19.989 to 20.000 mm
0.7869 to 0.7874 in.
-
11T Gear and one-way
clutch (I.D.)
24.007 to 24.020 mm
0.9452 to 0.9457 in.
-
11T Gear, 0ne-way clutch cam
and Mid-PTO shaft
Needle (O.D.)
1.997 to 2.000 mm
0.0786 to 0.0787 in.
-
Spiral bevel pinion Side clearance
Less than 0.15 mm
Less than 0.0059 in.
-
Backlash
0.10 to 0.30 mm
0.0039 to 0.012 in.
0.4 mm
0.016 in.
0.2 mm, 0.008 in. -
Spiral bevel pinion to spiral bevel
gear
Adjusting shim
(Thickness)
0.5 mm, 0.020 in. -
