TRANSMISSION
KUKJE MACHINERY CO., LTD.
69
3. SERVICING SPECIFICATIONS
Item Factory Specification Allowable Limit
Backlash
0.1 to 0.3 mm
0.004 to 0.012 in.
0.4 mm
0.016 in.
0.8 mm, 0.0315 in. -
1.0 mm, 0.0394 in. -
Differential pinion to differential
side gear
Adjusting shim
(Thickness)
1.2 mm, 0.0472 in. -
Clearance
0.025 to 0.066 mm
0.0016 to 0.0029 in.
0.30 mm
0.0118 in.
Differential case (I.D.)
32.000 to 32.025 mm
1.2598 to 1.2608 in.
-
Spiral bevel gear (I.D.)
32.000 to 32.025 mm
1.2598 to 1.2608 in.
-
Differential case to differential
side gear
Differential side gear
(O.D.)
31.959 to 31.975 mm
1.2598 to 1.2608 in.
-
Clearance
0.016 to 0.045 mm
0.0006 to 0.0018 in.
0.30 mm
0.0118 in.
Differential pinion
shaft (O.D.)
15.982 to 16.0 mm
0.6292 to 0.6299 in.
-
Differential pinion shaft to
differential pinion
Differential pinion (I.D.)
16.000 to 16.018 mm
0.6299 to 0.6306 in.
-
