REAR AXLE
KUKJE MACHINERY CO., LTD.
107
3. DISASSEMBLING AND SERVICING
<1> DISASSEMBLING AND ASSEMBLING
1) Separating Rear Axle Case
<Branson 2100, 2400(hst), 2800(hst)>
<Branson 2100, 2400, 2800 Euro>
< Draining transmission fluid >
1. Place an oil pan underneath the transmission
case, and remove the drain plugs(1).
2. Drain the transmission fluid.
3. Reinstall the drain plug.
▷ Refilling
9 Fill new oil into filling port after removing the
filling plug(2) up to the upper notch on the
dipstick(3).
9 After running the engine for few minutes, stop it
and check the oil lever again. If low, add oil to
proper level.
◈ Important
9 Use only multi-grade transmission oil. Use of
other oils may damage the transmission or
hydraulic system.
9 Never work the tractor immediately after
changing the transmission oil. Keep the engine
at medium speed for a few minutes to prevent
damage to the transmission.
9 Do not mix different brands oil together.
Front case
3.0 L
0.79 U.S.gals
0.66 lmp.fals
2100
2400
2800
Rear case
13.0 L
3.43 U.S.gals
2.86 lmp.gals
Transmission
fluid capacity
HST Rear case
15.0 L
3.96 U.S.gals
3.30 lmp.gals
*. PART NAME
1) Drain plug 2) Filling cap
3) Dipstick
A) Proper oil lever
(1)
(1)
(1)
(2)
(3)
