TRANSMISSION
KUKJE MACHINERY CO., LTD.
70
4. TIGHTENING TORQUES
Tightening torque of screws, bolts and nuts on the table below are especially specified.
Item N·m kgf·m ft-lbs
Rear wheel bolt and nut 108.0 to 125.0 11.0 to 12.7 79.0 to 92.2
3-Point hitch shaft setting screw 14.7 to 19.6 1.5 to 2.0 10.8 to 14.5
3-Point hitch shaft setting screw lock nut 43.0 to 47.0 4.4 to 4.8 31.7 to 35.4
Drawbar frame mounting screw 77.5 to 90.2 7.9 to 9.2 57.1 to 66.5
ROPS frame and frame top connecting bolt and nut 274.6 to 318.7 28.0 to 32.5 202.5 to 235.1
ROPS connecting plate mounting screw 123.6 to 147.0 12.6 to 15.0 91.1 to 108.5
ROPS frame mounting screw 77.5 to 90.1 7.9 to 9.2 57.2 to 66.5
Steering wheel mounting nut 48.1 to 55.9 4.9 to 5.7 35.4 to 41.2
Delivery pipe nut for HST 34.3 to 39.2 3.5 to 4.0 25.3 to 28.9
Oil cooler pipe nut 50.0 to 57.9 5.1 to 5.9 36.9 to 42.8
Delivery pipe nut for power steering 64.7 to 75.5 6.6 to 7.7 47.9 to 55.3
Power steering assembly mounting screw 48.1 to 55.9 4.9 to 5.7 35.4 to 41.2
Clutch housing and engines mounting screw (M8) 23.5 to 27.5 2.4 to 2.8 17.4 to 20.3
Clutch housing and engines mounting screw (M10) 48.1 to 55.8 4.9 to 5.7 35.5 to 41.2
Clutch housing and center frame mounting screw and
nut
77.5 to 90.2 7.9 to 9.2 57.1 to 66.5
Clutch housing rear cover mounting screw 23.5 to 27.5 2.4 to 2.8 17.4 to 20.3
Speed control rod screw 23.5 to 27.5 2.4 to 2.8 17.4 to 20.3
3-Point hitch delivery pipe joint bolt 34.3 to 39.2 3.5 to 4.0 25.1 to 28.7
HST (Transmission case) and center frame mounting
screw and nut
77.5 to 90.2 7.9 to 9.4 57.1 to 66.5
Spring holder mounting screw 39.2 to 44.1 4.0 to 4.5 28.9 to 32.5
Connecting plate mounting screw 39.2 to 44.1 4.0 to 4.5 28.9 to 32.5
Top link bracket mounting screw 77.5 to 90.1 7.9 to 9.2 57.2 to 66.5
Hydraulic cylinder mounting screw and nut 48.1 to 55.9 4.9 to 5.7 35.4 to 41.2
