Branson 2400 - Servicing Specifications

FRONT AXLE
KUKJE MACHINERY CO., LTD.
50
2. SERVICING SPECIFICATIONS
Item Factory Specification Allowable Limit
Front wheel alignment Toe-in
0.0 to 8.0 mm
0.0 to 0.315 in.
-
Front axle Rocking force
49.0 to 98.1 N
5.0 to 10.0 kgf
11.0 to 22.1 lbs
-
Clearance
0.032 to 0.068 mm
0.00126 to 0.00268 in.
0.2 mm
0.0079 in.
Differential case(I.D.)
15.000 to 15.018 mm
0.59055 to 0.59126 in.
-
Differential case to differential
pinion
Differential case(O.D.)
14.950 to 14.968 mm
0.5885 to 0.58929 in.
-
Spiral bevel pinion shaft Turning torque
0.8 to 1.0 Nm
0.08 to 0.10 kgfm
0.59 to 0.73 ft-lbs
-
Spiral bevel pinion shaft to spiral
bevel gear
Backlash
0.1 to 0.3 mm
0.004 to 0.012 in.
-
10T Bevel gear to 16T Bevel gear Backlash
0.1 to 0.3 mm
0.004 to 0.012 in.
-
Clearance
0.125 to 0.280 mm
0.0049 to 0.0110 in.
0.45 mm
0.018 in.
Front axle case
boss(O.D.)
49.950 to 49.975 mm
1.9665 to 1.9675 in.
-
Front axle case boss to bracket
bushing(Front)
Bracket bushing(I.D.)
50.10 to 50.23 mm
1.9722 to 1.9774 in.
-
Clearance
0.090 to 0.250 mm
0.0035 to 0.0098 in.
0.45 mm
0.018 in.
Front axle case
boss(O.D.)
64.94 to 64.97 mm
2.5567 to 2.5579 in.
-
Front axle case boss to bracket
bushing
Bracket bushing(I.D.)
65.06 to 65.19 mm
2.5614 to 2.5665 in.
-
