HYDRAULIC SYSTEM
KUKJE MACHINERY CO., LTD.
134
2. SERVICING SPECIFICATIONS
<1> POWER STEERING
Item Factory Specification Allowable Limit
Steering Wheel
<Operation Force Condition>
Engine Speed :
Approx. 2600 rpm,
Oil Temperature :
45 to 55℃ (133 to 131℉)
Less than 10.0 N
1.2 kgf
2.2 lbs
-
Rack(Piston) Assembly Axial Play
0.0 to 0.02 mm
0.0 to 0.00079 in.
0.004 mm
0.00157 in.
Clearance
0.17 to 0.28 mm
0.0067 to 0.0110 in.
0.40 mm
0.0157 in.
Sleeve (O.D.)
35.77 to 35.83 mm
1.4083 to 1.4106 in.
-
Valve Housing to Sleeve
Valve Housing (I.D.)
36.00 to 36.05 mm
1.4173 to 1.4193 in.
-
Sectorial Gear Shaft
to Rack(Piston)
Backlash Deflection
measured at pitman
arm end
Less than 0.30 mm
0.0118 in.
-
