FRONT AXLE
KUKJE MACHINERY CO., LTD.
51
3. TIGHTENING TORQUES
Item N·m kgf·m ft-lbs
Drag link slotted nut 17.7 to 34.5 1.8 to 3.5 13.0 to 25.3
Front wheel bracket mounting screw 77.5 to 90.1 7.9 to 9.2 57.1 to 66.5
Front axle bracket mounting screw 124.0 to 147.0 12.6 to 15.0 91.0 to 108.0
Bevel gear case mounting screw 77.5 to 90.1 7.9 to 9.2 57.1 to 66.5
Knuckle arm mounting screw (M10) 48.0 to 56.0 4.9 to 5.7 35.5 to 41.2
Knuckle arm mounting screw (M12) 103.0 to 117.7 10.5 to 12.0 76.0 to 86.8
Axle flange mounting screw 48.1 to 55.9 4.9 to 5.7 35.5 to 41.2
