Branson 2400 - Hydraulic Pump for Power Steering

HYDRAULIC SYSTEM
KUKJE MACHINERY CO., LTD.
146
4. CHECKING, DISASSEMBLING AND SERVICING
2) Hydraulic Pump for Power Steering
*. PART NAME
1) Suction hose 2) Hydraulic pump
3) Accelerator rod
4) Power steering delivery hose
5) Engine stop solenoid 6) 3-Point hitch delivery pipe
< Removing hydraulic pump >
1. Open the hood then remove the hood and
disconnect the battery grounding cord.
2. Disconnect the accelerator rod(3).
3. Disconnect the power steering delivery hose(4)
and 3-point hitch delivery pipe(6).
4. Disconnect the suction hose(1) and remove the
hydraulic pump(2).
▶ NOTE
1) For fastening the hydraulic pipe nut, use two
wrenches. Hold the fitting with a wrench, turn
the pipe nut with another wrench to avoid
damage at fitting installed part.
Tightening
torque
Delivery pipe nut
for power steering
65 to 75 N·m
6.6 to 7.7 kgf·m
47.9to55.3ft-lbs
