CLUTCH
KUKJE MACHINERY CO., LTD.
38
3. TIGHTENING TORQUES
Tightening torque of screws, bolts and nuts on the table below are especially specified.
Item N·m kgf·m ft-lbs
Steering wheel mounting nut 48.1 to 55.9 4.9 to 5.7 35.4 to 41.2
Delivery pipe nut for HST 34.3 to 39.2 3.5 to 4.0 25 to 28
Oil cooler pipe nut 50.0 to 57.9 5.1 to 5.9 36.9 to 42.8
Delivery pipe nut for power steering 64.7 to 75.5 6.6 to 7.7 47.9 to 55.3
Clutch housing and engine mounting screw (M8) 25.5 to 27.5 2.4 to 2.8 17.4 to 20.2
Clutch housing and engine mounting screw (M10) 48.1 to 55.8 4.9 to 5.7 35.5 to 41.2
Clutch cover mounting screw 23.5 to 27.5 2.4 to 2.8 17.4 to 20.2
