Branson 2400 - Front Axle Disassembly and Assembly

FRONT AXLE
KUKJE MACHINERY CO., LTD.
53
4. CHECKING, DISASSEMBLING AND SERVICING
<2> DISASSEMBLING AND ASSEMBLING
1) Separating Front Axle
*. PART NAME
1) Filling plug with dipstick 2) Drain plug
*. PART NAME
1) Propeller shaft cover 2) Spring pin
3) Coupling
< Draining front axle case oil >
1. Place the oil pan underneath the front axle case.
2. Remove the both the right and left hand side
drain plugs(2) and filling plug(1) to drain the oil.
3. After draining, reinstall the drain plugs(2).
▷ Refilling
9 Fill with new oil up to the upper notch on the
dipstick.
9 After fifteen minutes, check the oil level again,
add oil to proper level.
< Disconnecting propeller shaft >
1. Loosen the clamps and slide the propeller shaft
cover(1) to the rear.
2. Tap out the spring pin(2) and slide the
coupling(3) to the rear.
▷ Reassembling
9 Apply grease to the spline of the propeller shaft.
< Hydraulic hose >
1. Remove the hydraulic hose(1) from the front
cylinder assy(2).
*. PART NAME
1) Hydraulic hose 2) Front cylinder assy
(1)
(2)
(3)
