TRANSMISSION
KUKJE MACHINERY CO., LTD.
75
5. CHECKING, DISASSEMBLING AND SERVICING
*. PART NAME
1) Neutral valve (Forward)
2) Neutral valve (Reverse)
< Neutral valve actuation test >
To avoid personal injury :
Do not operate if tractor moves on level ground
with foot off speed control pedal.
When checking, park the tractor on flat ground,
apply the parking brake.
1. Disengage the front wheel drive lever.
2. Disconnect the brake rod or one side.
3. Lift the rear of tractor, one side.
4. Set the engine speed to 1500 rpm.
5. Shift the range gear shift lever to High position.
6. Move the HST pedal from the forward to the
neutral position make sure that the tire comes to
a stop. Check the same way for the movement
from rearward to the neutral potion. In this time,
make sure that the neutral range of HST.
7. If the tire fail to stop or neutral range is, check
the each neutral valve.
(1)
(2)
