GENERAL
KUKJE MACHINERY CO., LTD.
27
*. PART NAME
1) Brake pedal 2) Turnbuckle
3) Lock nut
L : Free travel
< Adjusting brake pedal free travel >
▶ Stop the engine and chock the wheels before
checking the brake pedal.
▶ The difference between the right and left pedal
free travel must be less than 4.0 mm (0.16 in.).
1. Release the parking brake.
2. Slightly depress the brake pedals and measure
the free travel at the top of the pedal stroke.
3. If the measurement is not within the factory
specifications, loosen the lock nut and turn the
turnbuckle to adjust the brake rod length.
4. Retighten the lock nut securely.
5. Keep the free travel in the right and left brake
pedals equal.
Brake pedal
free travel (L)
Factory spec.
30 to 40 mm
1.18 to 1.57 in.
▶ NOTE
1) After checking brake pedal free travel, be sure to
engage the parking brake lever fully and check
to see that the brake pedals are securely locked.
7. DISASSEMBLING AND SERVICING
