Installing a NetIron XMR 32000 router
3
Keep the following precautions in mind when mounting a NetIron XMR 32000 router in a rack:
DANGER
Make sure the rack or cabinet housing the router is adequately secured to prevent it from
becoming unstable or falling over.
Because of the weight of a fully loaded NetIron XMR 32000 router, it is recommended that you
mount the router in a rack before installing the modules and AC power supplies.
• You can install one NetIron XMR 32000 router in a standard 19-inch (EIA310-D) rack. YOu can
install your device in either a front-mount configuration or a mid-mount configuration using the
factory-installed mounting brackets. For a mid-mount configuration, simply remove the
mounting brackets from the front edges of the device and re-attach them to the center sides of
the device using the pre-drilled holes.
• You must provide eight standard #12-24 pan-head screws to secure the router in the rack.
Before performing this task, you should have an assembled rack and a #2 Phillips screwdriver.
• An empty NetIron XMR 32000 chassis weighs approximately 325 lbs. You must use a
mechanical device (such as a material lift or work positioner), and four people are required to
guide the router into place.
Follow these steps to install a NetIron XMR 32000 router in a rack.
NOTE
For better grounding of the router to the rack, attach the router using star washers. You can also use
star washers with single hole grounding lugs to prevent rotation of the lug.
1. Ensure the rack is in a permanent location and is secured to the building. Ensure that the
installation site allows adequate clearance for airflow, installation, and maintenance.
2. Move the pallet and router as close to the installation site as possible.
3. Use a power drill with a large Phillips screwdriver attachment to remove the four L-brackets that
attach the base of the router to the inner pallet. Refer to Figure 117.
FIGURE 117 L-brackets that secure the NetIron XMR 32000 router to the inner pallet
