182 Brocade MLX Series and NetIron XMR Hardware Installation Guide
53-1003821-01
Installing a NetIron XMR 32000 router
3
FIGURE 124 Routing upper-right quadrant cables up
1 Upper right quadrant 3 Cables from slot #15
2 Side combs (18) 4 Cables from slot #16
2
1
3
4
