Hardware specifications for NetIron XMR routers
8
• AC Operating Voltage Range: 90 - 264V, 50/60 Hz
• Inrush current: 40A peak maximum at 25 degrees C (77 degrees F)
• DC Input Rating: -48V, 30.0 A maximum per power supply
• DC Operating Range: -40 to -60V
• Inrush current: 45A peak maximum at 25 degrees C (77 degrees F)
The following power supply frequency requirements apply to NetIron XMR 32000 routers:
• AC Input Rating: 200 -240V, 50/60 Hz, 16.0 A maximum per power supply
• AC Operating Voltage Range: 180-264V
• Inrush current: 30A peak maximum at 25 degrees C (77 degrees F)
• DC Input Rating: -48V, 60.0 A maximum per power supply
• DC Operating Range: -40 to -60V
• Inrush current: 45A peak maximum at 25 degrees C (77 degrees F)
Table 49 lists the maximum power calculations for NetIron XMR routers.
Table 50 lists the maximum power consumption, in watts, for individual components within a
NetIron XMR router.
TABLE 49 NetIron XMR router power consumption values
Model @100 VAC @200 VAC @ 48 VDC
Amps Watts BTU/hr Amps Watts BTU/hr Amps Watts BTU/hr
Maximum per XMR (without 8x10G-X module)
NetIron XMR 4000 14 1384 4724 7 1384 4724 29 1384 4724
NetIron XMR 8000 28 2750 9386 14 2750 9386 57 2740 9386
NetIron XMR 16000 56 5572 19017 28 5572 19017 116 5572 19017
NetIron XMR 32000 N/A N/A N/A 57 11353 38476 237 11353 38476
Maximum per XMR (with any module)
NetIron XMR 4000 15 1503 5130 8 1503 5130 31 1503 5130
NetIron XMR 8000 30 2988 10198 15 2988 10198 62 2988 10198
NetIron XMR 16000 60 6048 20640 30 6048 20640 126 6048 20640
NetIron XMR 32000 N/A N/A N/A 62 12305 41996 256 12305 41996
TABLE 50 Maximum power consumption for NetIron XMR router components
Component Maximum power
consumption, in watts
Management modules
MR management module (NetIron XMR 4000, 8000 and 16000) 30W
MR management module (NetIron XMR 32000) 35W
MR2 management module (BR-MLX-MR-X for NetIron XMR 4000, 8000 and 16000) 40W
MR2 management module (BR-MLX-32-MR2-X for NetIron XMR 32000) 45W
Switch fabric modules
