34 Brocade MLX Series and NetIron XMR Hardware Installation Guide
53-1003821-01
Router modules
1
• 1800W AC or DC power supply
• 2100W AC or DC power supply
• 2400W AC or DC power supply
• 3000W AC or DC power supply
Table 17 lists the power supplies that are available for Brocade MLX and NetIron XMR routers.
Brocade MLX Series and NetIron XMR routers support the following power supply options:
• 4-slot router: Can accommodate three 1200W power supplies. For power redundancy you must
purchase additional power supplies depending on how you populate your router. For
determining the number of power supplies required for redundancy, refer to Chapter 7,
“Hardware Specifications”.
• 8-slot router: Can accommodate up to four 1200W or 1800W AC and DC power supplies.
Because power is supplied over a common power bus, any power supply installed in addition to
the minimum required provides backup for any supply that fails. For power redundancy, you
must purchase additional power supplies depending on how you populate your router. For
determining the number of power supplies required for redundancy, refer to Chapter 7,
“Hardware Specifications”.
• 16-slot router: Can accommodate eight 1200W or 1800W AC and DC power supplies. Because
power is supplied over a common power bus, any power supply installed in addition to the
minimum required provides backup for any power supply that fails. For power redundancy, you
must purchase additional power supplies depending on how you populate your router. For
determining the number of power supplies required for redundancy, refer to Chapter 7,
“Hardware Specifications”.
1800W AC power supplies support low and high line operation. For line voltages between 90 - 180,
the power supply operates at 1200W. For line voltages between 180 - 264, the power supply
operates at 1800W.
TABLE 17 Power supplies
Part number Description
BR-MLXE-ACPWR-1800 16-, 8- and 4-slot MLXe and 16- and 8-Slot XMR/MLX AC 1800W power supply.
BR-MLXE-DCPWR-1800 16-, 8- and 4-slot MLXe and 16- and 8-Slot XMR/MLX DC 1800W power supply.
NI-X-ACPWR 16-, 8- and 4-slot MLXe and 16- and 8-Slot XMR/MLX AC 1200W power supply.
NI-X-DCPWR 16-, 8- and 4-slot MLXe and 16- and 8-Slot XMR/MLX DC 1200W power supply.
NI-X-ACPWR-A 4-Slot NetIron XMR/MLX AC 1200W power supply.
NI-X-DCPWR-A 4-Slot NetIron XMR/MLX DC 1200W power supply.
BR-MLXE-32-ACPWR-3000 32-slot NetIron MLXe/XMR/MLX AC 3000W power supply.
BR-MLXE-32-DCPWR-3000 32-slot NetIron MLXe/XMR/MLX DC 3000W power supply.
NIBI-32-ACPWR-A 32-Slot NetIron MLXe/XMR/MLX AC 2400W power supply.
NIBI-32-DCPWR 32-Slot NetIron MLXe/XMR/MLX DC 2400W power supply.
