TABLE 8 Interface modules for all Brocade MLXe Series routers (continued)
SKU Ports Description Generation
NI-XMR-1Gx20-GC 20 NetIron XMR Series 20-port
10/100/1000 copper module with
IPv4/IPv6/MPLS hardware
support.
Gen 1
1
BR-MLX-1GCX24-X 24 XMR/MLXE 24-port
10/100/1000 Copper (RJ-45)
Module with IPv4/IPv6/MPLS
hardware support. Supports 1M
IPv4 routes in FIB.
Gen 1.1
BR-MLX-1GCX24-X-ML 24 MLX/MLXE 24-port
10/100/1000 Copper (RJ-45)
Module with IPv4/IPv6/MPLS
hardware support. Supports 512K
IPv4 routes in FIB. License
Upgradable to "X" scalability (1M
IPv4 routes in FIB).
Gen 1.1
BR-MLX-1GFX24-X 24 XMR/MLXE 24-port 1-GbE Fiber
(SFP) Module with IPv4/IPv6/
MPLS hardware support. Supports
1M IPv4 routes in FIB.
Gen 1.1
BR-MLX-1GFX24-X-ML 24 MLX/MLXE 24-port 1-GbE Fiber
(SFP) Module with IPv4/IPv6/
MPLS hardware support. Supports
512K IPv4 routes in FIB. License
Upgradable to "X" scalability (1M
IPv4 routes in FIB).
Gen 1.1
BR-MLX-10GX24-DM 24 MLXe 24-port 10-GbE Module
with IPv4/IPv6/MPLS hardware
support - requires SFPP optics.
Bandwidth up to 200Gbps per
module. Supports 256K IPv4
routes.
Gen 1.1
NI-MLX-1GX48-T-A 48 NetIron MLX Series 48-port
10/100/1000Base-T, MRJ21
module with IPv4/IPv6/MPLS
hardware support. Requires high
speed fans NIBI-16-FAN-EXH-A
on MLX-16.
Gen 1.1
1
Support is discontinued for Gen 1 cards (20x1G all avors; 4x10G all avors except 4x10-X; and 2x10G all avors).
Depending on your router model, you can install up to 32 single-slot interface modules, or 16 double-slot interface modules.
Interface modules are hot-swappable, which means you can remove and replace them without powering down the system.
NOTE
Specic information regarding RAD optics conguration on the Brocade MLXe Series platforms has been documented in the
RAD optics Solutions test report. Please work with your account team to gain access to the document.
2x100GbE CFP2 optics based high density module
The 100GbE 2-port CFP2 optics based high density blade is a half slot module card for the MLXe chassis.
The 2x100GbE CFP2 interface module is supported on all Brocade MLXe Series routers.
Router modules
Brocade NetIron MLXe Series Hardware Installation Guide
53-1004203-04 35
