Operation Manual
FT1020G3 Rev 2.4
50
First alarm: 002-03 Alarm number 1 (of 1)
Zone Address
002-03 SMOKE
User definable alarm text for 002-03.
1 zone in alarm
The presentation number is automatically followed by: SMOKE, HEAT, MULTI or MCP
depending on the type of alarm point.
More than one alarm point activating fire alarm.
Example; fire alarm in zone 002, address 03 (within zone 002) and nine other fire alarms
(of which the latest alarm is 003-11) in four different zones:
First alarm: 002-03 Alarm number 1 (of 10)
Zone Address
002-03 SMOKE
User definable alarm text for 002-03.
Latest alarm: 003-11 4 zone in alarm
"SMOKE" next to the presentation number is automatically added depending on the type
of alarm point (i.e. SMOKE, HEAT, MULTI or MCP).
User definable alarm text, for each alarm point and zone line input, an individual alarm
text can be shown. Each zone has its own individual alarm text (if programmed). Up to 40
alphanumeric characters can be used.
Additional information
First alarm, Latest alarm, Alarm number and number of zones in alarm.
LEDs "SEVERAL ALARMS" (L6) blinking (0.4 / 0.4 sec.) are indicating that more than one
fire alarm is activated. To scroll through the alarm points, use the push button "SEVERAL
ALARMS" (P9).
Next zone. Use the soft key "Next zone" (P6) to scroll through the zones in alarm.
When scrolling through the zones, the first alarm point activated in the next zone will be
shown. The "Next zone" button will be available only if there are alarms in more than one
zone.
The first alarm will be automatically displayed again, 20 seconds after the latest time the
"SEVERAL ALARMS" or "Next zone" buttons where used.
The printer (if available) will print each fire alarm, e.g.:
