Operation Manual
FT1020G3 Rev 2.4
71
FAULT: Supervised input x Expansion Board x, Control Unit xx
A fault on the supervised input x on the Expansion Board 4583 with
address x, in Control Unit no. xx.
Check the cables / connections (cut-off or short-circuit).
FAULT: Supervised input x, technical number xxxxxx
A fault on the supervised input x on 4461 / 4462.
Check the cables / connections (cut-off or short-circuit).
FAULT: Supervised output x, Control Unit xx
If the output is programmed for sounders or OWS (type "Alarm
devices"), it is also indicated by LED Fault / Disablements" Alarm
devices" (L11) blinking.
If the output is programmed for Fire Brigade TX (type "Routing
equipment"), it is also indicated by LED Fault / Disablements" Fire
brigade TX" (L12) blinking.
If the output is programmed for an extinguishing system (type
"Extinguishing"), there will be an additional information text close to the
soft key area in the display:
Extinguishing wire fault.
• x=0 (S0): Short circuit/break on the connected cable/ equipment
and/or blown fuse F4 on the main board 5010.
• x=1 (S1): Short circuit/break on the connected cable/ equipment
and/or blown fuse F5 on the main board 5010.
• x=2 (S2): Short circuit/break on the connected cable/ equipment
and/or blown fuse F6 on the main board 5010.
• x=3 (S3): Short circuit/break on the connected cable/ equipment
and/or blown fuse F7 on the main board 5010.
o Fuse T500mA L 250V (TR5).
o Calibration not performed via menu H5/A1.
o Connected equipment might be "missing".
o End of line resistor(s) missing or not correct value (1-5
resistors 33K)
Note: The calibrated value has to be in the range 1K-50K.
FAULT: Supervised output x Expansion Board x, Control Unit xx
A fault on the supervised output x on the Expansion Board 4583 with
address x, in Control Unit no. xx.
If the output is programmed for sounders (type Alarm devices), it is
also indicated by LED Fault / Disablements "Alarm devices" (L11)
blinking.
If the output is programmed for Fire Brigade TX (type Routing
equipment), it is also indicated by LED Fault / Disablements" Fire
brigade TX" (L12) blinking.
• Calibration not performed via menu H5/A1.
• Short-circuit / break on the connected cable / equipment.
• Blown fuse F1 (Output 0) or F2 (Output 1) on the 4583 board.
Fuse T200mA L 250V (TR5).
• Connected equipment may be "missing".
• End-of-line resistor(s) missing or not correct value, 1-5 resistors
(33K).
Note: The calibrated value has to be in the range 1K-50K.
FAULT: Supervised output x, technical number xxxxxx
This fault message is valid for a COM loop output unit 3364 output or
4464 output.
If the output is programmed for sounders (type Alarm devices), it is
also indicated by LED Fault / Disablements "Alarm devices" (L11)
