Operation Manual
FT1020G3 Rev 2.4
72
If the output is programmed for Fire Brigade TX (type Routing
equipment), it is also indicated by LED Fault / Disablements "Fire
Brigade TX" (L12) blinking.
• Calibration not performed via menu H5/A1.
• Short-circuit / break on the connected cable / equipment.
• Connected equipment might be "missing".
• End-of-line capacitor(s) missing or not correct value, 1-5
capacitors (470 nF).
Note: The calibrated value has to be in the range 470 nF – 5 x 470
nF (2350 nF). (valid for 3364 only)
FAULT: Temperature sensor, Control Unit xx
The sensor is not correctly connected or is missing.
FAULT: TLON-board (Network 0), Control Unit xx
FAULT: TLON-board (Network 1), Control Unit xx
TLON connection board 5090.
No communication / connection with the TLON network. The board for
Network 0 or 1 in Control Unit no. xx has to be replaced.
FAULT: Wrong information, Control Unit xx
Can be shown in conjunction with new software download and/or when
commissioning a system. This fault can be generated d
TLON network, i.e. communication problems.
One or more Control Units may have data stored that is not the same in
all Control Units. If a Control Unit restarts in conjunction with this fault,
a synchronisation will start automatically, otherwise a synchronisation
has to be started via menu H8/S8 (or via EBLWin).
Note: It is important that all Control Units that are supposed to exist
(SSD downloaded via EBLWin) are running and are connected to the
TLON network. The TLON network programming has
It will take 90-120 seconds until this fault is corrected.
FAULT: Wrong type Expansion Board x loop x, Control Unit xx
This is valid for the I/O Matrix board 4582 no. x connected on COM loop
x in the Control Unit no. xx.
Check the board type, set with jumpers JP4 and JP5 on the I/O Matrix
board. The type should be the same as it is programmed via EBLWin.
FAULT: Wrong type, Expansion Board x, Control Unit xx
Valid for the 8 zones exp. board 4580, 8 relay outputs exp. board
4581 and Inputs / outputs exp. board 4583, mounted in Control Unit
no. xx.
Check the type of board, which should be the same as programmed
FAULT: Wrong type of unit xxxxxx
Check the type of unit, which should be the same as programmed via
EBLWin.
