Programmer
142
Chapter 3 Programming with Command Function
Example of modified program
This section describes the modification method of the program using examples. Refer to "Programming"
(page 161) .
Resizing pattern
The programmed pattern is resized. The example in
the left is used for explanation.
The center point (reference point) of resizing can be changed. The magnifying direction varies depending on the
position of the reference point.
If the reference point is not determined, the pattern is resized to the home position.
If the reference point is determined, the pattern is resized to the reference point.
1
Calling data
1. Specify the program number on the
operation panel and press the read/write
switch to read the data.
Reference point
(Home position)
Reference point
To Next Page
