Programmer
161
Chapter 3 Programming with Command Function
Programming
Creating a line
Command to be used
LI
LI
Input the stitch length in
.
Example
Pitch
Input
0.5 mm
005
12.0 mm
120
1.
Select the sewing start position with
and press
L
.
2.
Input the stitch length in 3 digits and press
LI
LI
.
3.
Move the needle with
and press
L
.
161
163
