Brother BAS-311E - Programming Example; Programming for each Stitch

Programmer
25
Chapter 2 Programming with Help Function
Programming example
Frequently used programming method is explained here. Refer to "Programming" (page 83) for function
and operation of each icon.
Programming for each stitch
Program each stitch according to the pattern. The
example in the left is used for explanation.
1
Programming
1. Press
P
.
The work clamp moves to the home position and the
programmerscreenisdisplayed.
2. Select with and press .
3. Move the work clamp with
. Press
when the needle point is at point A of the
pattern.
Thefirststitch (pointA) isprogrammed.
4. Select with and press .
5. Move the work clamp with
. Press
when the needle point is at point B of the
pattern.
6. Repeat step 5 and create the program to
point C.
