Brother BAS-311E - Splitting

Programmer
44
Chapter 2 Programming with Help Function
Splitting
Different patterns, splitting each pattern in sequence,
are programmed. The example in the left is used for
explanation of 3 patterns in sequence.
1
Programming
1. Press
P
.
The work clamp moves to the home position and the
programmer screen is displayed.
2. Select with and press .
3. Move the work clamp with
. Press
when the needle point is at point A of the
pattern.
The first stitch (point A) is programmed.
4. Program pattern 1.
5. Press

ESCESC
when the needle point is at point
B of the pattern.
The number of pressing

ESCESC
depends on the programming
method for pattern 1.
6. Select with and press .
7. Move the work clamp with
. Press
when the needle point is at point C of the
pattern.
Pattern 1
Pattern 2
Pattern 1
Pattern 2
