Brother BAS-311E - Lines

Programmer
29
Chapter 2 Programming with Help Function
Lines
The pattern with lines is programmed.
The example in the left is used for explanation of
programming.
1
Programming
1. Press
P
.
The work clamp moves to the home position and the
programmerscreenisdisplayed.
2. Select with and press .
3. Move the work clamp with
. Press
when the needle point is at point A of the
pattern.
Thefirststitch (pointA) isprogrammed.
4. Select with and press .
5. Input the stitch length and press
.
3.0mmisinputintheexample.
Input030tomakethestitchlengthto3.0mm.
6. Move the work clamp with . Press
when the needle point is at point B of the
pattern.
7. Repeat step 6 and create the program to
point E.
8. When point E is programmed, press

ESCESC
twice.
