Brother BAS-311E - Curve

Programmer
31
Chapter 2 Programming with Help Function
Curve
The pattern with curves is programmed.
The example in the left is used for explanation of
programming at the curve and the corner.
Besuretopress
twiceforasplitatcornerpointsCorE.Ifasplitisnotmade,thecornerwillberound.
When a split is made When a split is not made
MoreintermediatepointssuchaspointsB,D,ForGwillcreatesmoothcurves.
1
Programming
1. Press
P
.
The work clamp moves to the home position and the
programmerscreenisdisplayed.
2. Select with and press .
3. Move the work clamp with . Press
when the needle point is at point A of the
pattern.
Thefirststitch (pointA) isprogrammed.
4. Select with and press .
