Brother BAS-311E - Moving a Part of Continuous Program in Parallel

Programmer
78
Chapter 2 Programming with Help Function
Moving a part of continuous program in parallel
A part of continuous program is moved in parallel.
The example in the left is used for explanation of
moving patterns B an C in parallel.
1
Calling data
1. Press
P
.
The work clamp moves to the home position. The programmer
screen is displayed.
2. Select with and press .
3. Select
with and press .
4. Input the data number and press
.
5. Press

ESCESC
.
2
Moving to position 1
1. Select with and press .
2. Press
9
9 9
and press .
The work clamp moves from the start position by each stitch.
Feed
Pattern A Pattern B Pattern C
