Brother BAS-311E - Creating Needle Drop Data; Creating Feed Data

Programmer
92
Chapter 2 Programming with Help Function
Creating needle drop data
Create needle drop data for the current needle position.
1. Select
and press .
2. Move the needle with , then press .
Creating feed data
Create ( feed ) data to move the needle to the next position without needle drop at the current
position.
1. Select
and press .
2. Move the needle with , then press .
Remaining plot count
Distance from the previous point in the
direction of X or Y axis
Remaining plot count
Distance from the previous point in the
direction of X or Y axis
