Programmer
47
Chapter 2 Programming with Help Function
4. Select with and press .
5. Select with and press .
6. Input the zigzag width and the stitch length
and press .
3.0 mm is input in the example.
Input 030 to make the width and the stitch length to 3.0 mm.
To switch input between the stitch length and the width, use
.
7. Move the work clamp with . Press
when the needle point is at point B of the
pattern.
To program curves, repeat this step.
8. Press again.
9. Press
ESCESC
three times.
2
Inputting the end code
1. Select with and press .
2. Select the end code type with
and
press
.
"111" is selected in the example. Press and the work clamp
returns to the first stitch(point A).
3. Press
ESCESC
.
The work clamp returns to the home position.
