Brother DCP-8065DN Service Manual

App. 4-10 Confidential
- Selectors 1 through 3: Redial/Pause key setting and 2nd dial tone detection
Selectors
1 2 3
0 0 0 No WAIT is inserted even if the [Redial/Pause] key is pressed.
0 0 1
0 1 0
0 1 1
1 0 0
If you press the [Redial/Pause] key during dialing, the machine will insert
WAIT as defined in the above table.
If the [Redial/Pause] key is pressed repeatedly, the machine inserts the
specified WAIT multiplied by the number of depressions. It applies also in
hook-up dialing.
1 0 1
1 1 0
1 1 1
When these selectors are set to "1, 0, 1":
Each time you press the [Redial/Pause] key in dialing, the machine will wait
for the 2nd dial tone to be sent via the communications line regardless of
pulse dialing or tone dialing.
When these selectors are set to "1, 1, 0":
If you press the [Redial/Pause] key in pulse dialing, the machine will first
wait for the 2nd dial tone to be sent via the communications line. After that,
pressing the [Redial/Pause] key will cause the machine to insert a WAIT of
3.5 seconds. In tone dialing, the machine will insert a WAIT of 3.5 seconds.
When these selectors are set to "1, 1, 1":
If you press the [Redial/Pause] key, the machine will first wait for the 2nd
dial tone to be sent via the communications line regardless of pulse dialing or
tone dialing. After that, pressing the [Redial/Pause] key will cause the
machine to insert a WAIT of 3.5 seconds.
(In those countries where no dial tone detection function is supported, setting
these selectors to "1, 0, 1," "1, 1, 0," or "1, 1, 1" inserts a WAIT of 3.5
seconds.)
- Selectors 4 through 6: Detection of international tone
Upon detection of the 2nd dial tone for the time length specified by these selectors, the machine
starts dialing.
This setting is effective only when the 2nd dial tone detection function is activated by selectors 1
through 3 (Setting 101, 110, or 111).
This function does not apply in those countries where no dial tone detection function is supported.
- Selector 7: No. of 2nd dial tone detection cycles
This selector sets the number of dial tone detection cycles required for starting dialing.
- Selector 8: Allowable instantaneous interrupt during reception of 2nd dial tone
This selector sets the allowable instantaneous interrupt period that should be ignored during
reception of the 2nd dial tone.

Brother DCP-8065DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	28 ppm
Scan to	e-mail, file, image, OCR
Input color depth	48 bit
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	28 cpm
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Internal memory	32 MB
Maximum internal memory	544 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	55 dB
Display	LCD
Market positioning	Business
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Font styles	66 Scaleable fonts, Letter, Gothic 16.66, OCR-A, OCR-B, 11 Barcodes
Dimensions (WxDxH)	531 x 450 x 475 mm
Networking features	10/100 Base-TX
All-in-one functions	Copy, Scan
Color all-in-one functions	scan, n
Compatible operating systems	Mac OS X 10.2.4 or greater Windows XP
Standard interfaces	USB 2.0
Sustainability certificates	ENERGY STAR
Power consumption (standby)	85 W
Power consumption (PowerSave)	15 W
Power consumption (average operating)	660 W
