Brother DCP-8065DN - Scanner Mechanism

Confidential
3-3
3.2.1 Scanner Mechanism
<Duplex scanning mechanism>
This mechanism consists of the document cover, the scanner unit (scanner cover), and the
automatic document feeder (ADF).
The scanner unit consists of a scanner top cover, CCD unit and scanner base.
Fig. 3-3
Pulle
y
ASSY
Bel
t
CCD module
Guide shaf
t
Top cove
r
White-level reference fil
m
ADF
ADF & documen
t
cover ASSY
Scanner uni
t
(Scanner cover)
Scanner base
Document cove
r
