Brother MFC-8380DN Service Manual

3-10
Confidential
Error
codes
Problem
Refer
to:
Error
codes
Problem
Refer
to:
7F
Fax paper setting mismatch
(The setting paper becomes
besides the A4/Letter/Legal/
Folio) (Not applicable)
3-23 AD
DMA transfer error
3-31
80
Fax paper size is incorrect (The
paper is smaller 10mm than the
letter size (11inch) in Fax List/
Report)
3-23 AE
Document scanner home
position sensor is not turned on.
3-31
83
Failure of discharge detection
(Printing becomes unable until the
drum is replaced with a new one.)
(Discharge detection becomes
unable until the drum counter
reaches the double of the drum
life.)
3-23 AF
Document scanner home
position sensor is not turned off.
3-32
84
Paper jam
3-24 B0
Document scanner unit FFC
detection error
3-32
85
Tray 1 is not installed into the
machine
3-24 B1
Dark level offset data level error
for scanning
3-33
86
Tray 2 is not installed into the
machine
3-24 B2
Gain control data level error for
scanning
3-33
88
Paper jam inside the machine
3-25 B7
A/D converter standard voltage
failure; at High side
3-33
89
Incorrect paper size in duplex
printing
3-25 B8
A/D converter standard voltage
failure; at Low side
3-33
8A
Paper jam in Tray 1
3-26 B9
Scanning light adjustment error
is detected
3-34
8B Paper jam in Tray 2 3-26 BB White level data error 3-34
8C Paper jam in MP Tray 3-26 BD Black level data error 3-34
8D
Paper jam near eject tray
3-27 BF
ADF duplex scanning cannot be
implemented due to too long
document
3-34
99
Specified paper size is not supported
for duplex printing (Duplex)
3-27 C0
New toner detection lever failure
3-35
9F Paper empty 3-28 C7 Insufficient DIMM Memory 3-35
A1 Front cover opened 3-28 C8 Secure print data full 3-35
A2
During scanning, 90 cm or longer
of a document is detected
3-29 C9
DIMM error
3-36
A3
Document rear sensor is not
turned on when feeding the
document
3-29 CA
Excess current to USB device
that is front side of the machine 3-36
A4
ADF cover opened
3-29 CD
Drum unit is not installed into the
machine
3-36
A5
Fax scanning error (Warning)
(First time)
3-30 D1
Modem initialization failed
3-37
A6
Fax scanning error (Error)
(Second time) 3-30 DD
Fuser error other than 58, 59,
68, 69, 6A, 6B, 6C, 6D, 6E, 6F,
76, 78, DE and E2 are occurred
3-37
A7
Scanning color parameter file
failure 3-30 DE
Central temperature of heat
roller detected the temperature
that was lower than 60°C)
3-37
A8
Scanning color parameter
matching error
3-30 E0
Program error
3-37
