Brother MFC-8380DN Service Manual

3-7
Confidential
Not Registered You tried to access a One
Touch or Speed Dial
number that is not
programmed.
Set up the One Touch or Speed Dial
number.
3-74
Out of Memory The machine’s memory is
full.
Fax sending or copy operation in
progress
Do one of the following:
Press Start to send or copy the
scanned pages.
Press Stop/Exit and wait until the
other operations in progress finish,
and then try again.
Clear the data from the memory.
Print operation in process
Do one of the following:
Reduce print resolution.
Clear the faxes from the memory.
3-35
Print Unable XX The machine has a
mechanical problem.
Perform processing with the error
code.
3-12
3-13
3-18
3-19
3-20
3-21
3-37
3-38
3-39
Protected Device The protect switch of the
USB Flash memory drive
is on.
Turn off the protect switch of the USB
Flash memory drive. 3-36
Rename the File There is already a file on
the USB Flash memory
drive with the same name
as the file you are trying to
save.
Change the file name of the file on
the USB Flash memory drive or the
file you are trying to save.
-
Replace Parts
Drum or
Replace Drum
The drum unit is the end of
its life.
Replace the drum unit.
3-14
The drum unit counter was
not reset when a new drum
was installed.
1) Open the front cover, and then
press Clear/Back.
2) Press 1 to reset.
Replace Parts
Fuser Unit or
Replace Fuser
It is time to replace the
fuser unit.
Replace the fuser unit.
3-15
Replace Parts
Laser Unit or
Replace Laser
It is time to replace the
laser unit.
Replace the laser unit.
3-15
Replace Parts
PF Kit MP or
Replace PF Kit
MP
It is time to replace the
paper feeding kit for the
MP tray.
Replace the PF Kit MP.
3-14
Replace Parts
PF Kit 1 or
Replace PF Kit 1
It is time to replace the
paper feeding kit for Tray
1.
Replace the PF Kit 1.
3-15
Error Message Type of Error Action
Refer
to

Brother MFC-8380DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Scan to	e-mail, FTP, OCR, USB
Input color depth	48 bit
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	4, 9, 16, 25
Copy speed (black, normal quality, A4)	30 cpm
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Total input capacity	500 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Auto document feeder (ADF) input capacity	20 sheets
Internal memory	64 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	56 dB
Display	LCD
Market positioning	Home & office
Custom media sizes	(69.8 - 216) x (116 - 406.4) mm
Dimensions (WxDxH)	531 x 451 x 475 mm
Networking features	10/100 Base-TX
All-in-one functions	Copy, Fax, Scan
Maximum internal memory	0.576 GB
Color all-in-one functions	scan, n
Compatible operating systems	Linux, Windows 2000, XP/2003, Vista, XP, Mac OS X 10.3.9
Maximum print size	216 x 297 mm
Media weight (tray 1)	60 - 105 gsm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Supported network protocols (IPv4)	IPv4, IPv6
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	85 W
Power consumption (PowerSave)	19 W
Power consumption (average operating)	680 W
Package weight	21100 g
