Brother MFC-8380DN Service Manual

3-8
Confidential
Replace Parts
PF Kit 2 or
Replace PF Kit 2
It is time to replace the
paper feeding kit for Tray
2.
Replace the PF Kit 2.
3-15
Replace Toner The toner cartridge is used
up and printing is not
possible.
Replace the toner cartridge with a
new one. 3-17
Scan Unable XX The machine has a
mechanical problem.
Perform processing with the error
code.
-
Document is too long for
duplex scanning.
Press Stop/Exit. Use the suitable
size of paper for duplex scanning.
Scanner Locked The scanner lock is locked. Open the document cover, and then
release the scanner lock lever.
Press Stop/Exit.
3-32
Size mismatch The paper in the tray is not
the correct size.
Load the correct size of paper in the
tray and set the “Paper Size”.
3-23
Toner Low If the LCD shows Toner
Low, you can still print;
however, the machine is
telling you that the toner
cartridge is near the end of
its life.
Order a new toner cartridge now.
3-17
Too Many Files There are too many files
stored on the USB Flash
memory drive.
Reduce the number of files stored on
the USB Flash memory drive.
-
Too Many Trays More than one optional
tray is installed.
The maximum number of optional
trays is one. Remove any additional
trays.
-
Unusable Device An incompatible or broken
device has been
connected to the USB
direct interface.
Remove the USB Flash memory
drive from the USB direct interface. 3-36
3-40
Error Message Type of Error Action
Refer
to

Brother MFC-8380DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Scan to	e-mail, FTP, OCR, USB
Input color depth	48 bit
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	4, 9, 16, 25
Copy speed (black, normal quality, A4)	30 cpm
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Total input capacity	500 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Auto document feeder (ADF) input capacity	20 sheets
Internal memory	64 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	56 dB
Display	LCD
Market positioning	Home & office
Custom media sizes	(69.8 - 216) x (116 - 406.4) mm
Dimensions (WxDxH)	531 x 451 x 475 mm
Networking features	10/100 Base-TX
All-in-one functions	Copy, Fax, Scan
Maximum internal memory	0.576 GB
Color all-in-one functions	scan, n
Compatible operating systems	Linux, Windows 2000, XP/2003, Vista, XP, Mac OS X 10.3.9
Maximum print size	216 x 297 mm
Media weight (tray 1)	60 - 105 gsm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Supported network protocols (IPv4)	IPv4, IPv6
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	85 W
Power consumption (PowerSave)	19 W
Power consumption (average operating)	680 W
Package weight	21100 g
