If your LCD error message was [Repeat Jam A Inside/Front], move the print head (if needed) to
take out any paper remaining in this area. Make sure scraps of paper are not left in the corners of the
machine (1) and (2).
When finished, continue with the next step.
IMPORTANT
• DO NOT touch the encoder strip, a thin strip of plastic that stretches across the width of the machine
(1). Doing this may cause damage to the machine.
• If the print head is in the right corner as shown in the illustration (2), you cannot move the print head.
Close the scanner cover, and then reconnect the power cord. Open the scanner cover again, and
then hold down until the print head moves to the centre. Then unplug the machine from the
power source and take out the paper.
• If the paper is jammed under the print head, unplug the machine from the power source, and then
move the print head to take out the paper.
Hold the concave areas with the triangle marks shown in the illustration (3) to move the print head.
422
