SMART KTF 2000 – KTF/RW Operation
SMART KTF 2000 3B-37 -
4.1) MOT DIRECT= P4.2
Press
to enable the parameter programming
This function allows you to choose the rotation direction of the yarn feeding motor.
CW = Clockwise direction
CCW= Counter-Clockwise direction
Choose the desired direction using
.
Press
to continue
4.4) MOT TYPE= P4.4
Press
to enable the parameter programming
This function allows you to choose the type of motor used on KTF/xxx RW yarn
feeding device.
[allowed values F01 – F02 (01 = 25 mN/m; 02 = 100 mN/m)]
Choose the desired direction using
,
Press
to continue.
MOT TYPE is the last programmable parameter of the list concerning the relevant
article. Pressing
you will have the possibility to save the article (with the
values setup).
Pressing
with this screen completes the article modification phase and the
> MODIFY menu item will re-appear.
This screen display for a few seconds indent that the parameters are going to be
saved into the database of SMART KTF 2000 terminal.
This screen allows you to save with a new name (AAAAAAA), the modified
parameters; to enter the new name use
, ,
If the article that has just been modified is currently loaded into the KTF/RW
devices, this screen gives you the possibility to load the changes into the devices
themselves.
Press
to reload the changes or press to leave the function without
reloading.
