Buchi E-800 - Configuration; Front View (with Chamber Heater)

BÜCHI Labortechnik AG Product description | 3
Operation Manual UniversalExtractor E-800 17/88
3.2 Configuration
3.2.1 Front view (with chamber heater)
4
3
5
6
13
12
1
2
7
8
9
11
10
Fig.2: Front view
1 Protection shield 2 Condenser rack
3 Chamber rack 4 Condenser tank bottle
5 Installation board 6 Tank bottle
7 Heating plate 8 Analyte protection sensor
9 Beaker rack 10 Chamber heater
11 Inert gas connection 12 On/Off master switch
13 Pro Interface
