BÜCHI Labortechnik AG Operating the interface pro | 6
Operation Manual UniversalExtractor E-800 47/88
Symbol Description Meaning
O K
[ Confirm ] Confirms an entry.
DELETE
[ Delete ] Deletes the selected method or step.
S AV E
[ Save ] Saves the setting.
M E N U
[ Menu ] Allows selection of a menu from the
menu bar using the navigation con-
trol.
S TA RT
[ Start ] Starts the extraction process.
STOP
[ Stop ] Aborts extraction on all extraction
positions.
U P
[ Up ] The lift moves up.
D O W N
[ Down ] The lift moves down.
QR Code
[ QR Code ] The display shows a QR Code which
contains the data of all extraction pa-
rameters.
[ New ] Saves a new setup
LOAD
[ Load ] Loads setup
6.3 Menu bar
The menus are represented by symbols on the menu bar. Navigation through the
menus is by input controls.
The following menus are available:
Menu symbol Meaning Submenu/Actions
[ Home ] menu  Process control param-
eters
[ Setup ] menu  For saving the individual
settings for the extrac-
tion positions
[ Method ] menu  For saving extraction
methods
 Editing and activating
[ Configuration ] menu  Change settings
 Service menu
 System information
