Buchi E-800 - Front View (Without Chamber Heater)

3 | Product description BÜCHI Labortechnik AG
18/88 Operation Manual UniversalExtractor E-800
3.2.2 Front View (without chamber heater)
4
5
11
10
1
2
3
6
7
8
9
Fig.3: Front view
1 Protection shield 2 Condenser rack
3 Chamber rack 4 Condenser tank bottle
5 Tank bottle 6 Beaker rack
7 Installation board 8 Analyte Protection sensor
(Option)
9 Heating plate 10 On/Off master switch
11 Pro Interface
