BÜCHI Labortechnik AG Operating the interface pro | 6
Operation Manual UniversalExtractor E-800 55/88
u Tap the function [ OK ] on the function bar.
ð The dialog box closes.
u Tap the function [ Save ] on the function bar.
ð The value is saved.
6.6.7 Setting the extraction cycles of a method (Soxhlet and Soxhlet Warm
Extraction)
The extraction time and the number of extraction cycles are interdependent.
If the number of extraction cycles is set to zero, the extraction will finish after the
selected time.
If the extraction time is set to zero, the extraction will finish after the number of ex-
traction cycles is reached.
If the extraction time and a number of extraction cycles is set, the extraction will fin-
ish once both settings are fulfilled.
The number of extraction cycles is selectable from 0 to 5940.
Navigation path
➔
u Navigate to the [ Method ] menu via the navigation path.
u Tap the name of the method that you wish to edit.
ð The display shows the view Method.
u Tap the function [ Edit ] on the function bar.
u Tap the action [ Extraction cycle ].
ð The display shows a dialog box with a numeric input box.
u Enter the value in the numeric input box.
u Tap the function [ OK ] on the function bar.
ð The dialog box closes.
u Tap the function [ Save ] on the function bar.
ð The number of extraction cycles is saved.
6.6.8 Setting the extraction heating level of a method
The default setting for the heating level setting is the selected solvent.
Change the heating level to compensate different air pressure.
The heating steps are selectable from 0 to 20.
Navigation path
➔
u Navigate to the [ Method ] menu via the navigation path.
u Tap the name of the method that you wish to edit.
ð The display shows the view Method.
u Tap the function [ Edit ] on the function bar.
u Tap the action [ Extraction heating level ].
ð The display shows a dialog box with a numeric input box.
u Enter the value in the numeric input box.
