3.2.3 Rear view
1
2
Fig.4: Rear view
1 Upper connections
See Chapter3.2.4 "Upper connec-
tions on the rear side", page19
2 Lower connections
See Chapter3.2.5 "Lower connec-
tions on the rear side", page20
3.2.4 Upper connections on the rear side
1
2
3
4
Fig.5: Connections on the top
1 Standard BUCHI communication port
(COM)
2 Standard BUCHI communication port
(COM)
3 LAN port 4 Port for the cooling water valve
